3FB40

(3 Panel) (4-Color) (One Sided) (with Bleed)

Size Specifications:

• Live Image Area: 7.9167 inches x 10 inches (570 points x 720 points)
• Trim: (this is where the paper will be cut – Do not build to this size): 8.25 inches x 10.5 inches (594 points x 756 points)
• Bleed: 8.4167 inches x 10.75 inches (606 points x 774 points)

3FB40: Is a Bleed** product. Background images and art elements should extend to the Bleed size. Keep all layout elements that you don’t want to be trimmed or cropped, inside of the Live Image Area.

** IMPORTANT Note about Bleed Products: Valpak’s templates are intentionally built without bleed settings applied. If using a Valpak template and your product calls for a bleed, do not enter any bleed settings. Instead, simply build your layout according to the bleed margins designated on the template.

Click HERE to download the 3-Panel InDesign templates (Horizontal and Vertical Layouts).

Examples of properly built 3FB40 products:

Horizontal Layout visual showing the Bleed, Trim, Live Area, and indicating where the Fold and Gutters are located.

Vertical Layout visual showing the Bleed, Trim, Live Area, and indicating where the Fold and Gutters are located.

How to build this product:

!!! INCORRECT:

Vertical Layout visual showing an incorrectly built 3FB40 product. Notice that there’s not enough of the black background extending to the Bleed size. This will result in the black background being trimmed short, resulting in white paper showing around the layout edges.

CORRECT:

Vertical Layout visual showing a correctly built 3FB40 product. The background is fully extending to the bleed size, and all the important layout elements are completely within the Live Image Area.
